ELECTRONIC CONTROL
Electronic control CC-Touch
All cleaning operations can be controlled from the high-quality CC-Touch screen display.
- High-quality glass design
- Simple to use
- 100 % operational reliability
The easy to understand controls with a large TFT colour graphic display ensures simple operation. An operation log according to DIN can be easily kept using CC-Touch.
CC-Insight
The smart control module for PC data transmission and visualisation
CC-Insight provides an intelligent software solution which allows all relevant data, functions and operating procedures to be stored on the machine itself, including the operating logs required for compliance with standards such as DIN 10510. This data can then be transferred to a local PC and displayed in the form of function-specific diagrams and animated depictions of machine processes. The software also enables users to analyse and diagnose the machine’s operating status.
CC-Insight allows users to update operating logs by manually entering data on cleaning procedures, water changes, repairs, and replacement of detergent/rinse aid containers. It also enables users to integrate their equipment into a network, to link up multiple units, and to connect machines to a control room or a kitchen or facility management system. Data can be transmitted via a serial interface (RS 232/422), LAN/W-LAN, GSM/GPRS or LAN and GSM/GPRS. GSM can be used for SMS and e-mails.
CC-Insight comes with an update function which provides convenient access to software upgrades and updates.
CC
The control module for operating logs and data transfer
Using Bluetooth technology, CC communicates with the machine’s control system to transfer and save all relevant system and hygiene data in a matter of seconds. The licensed software package wirelessly retrieves the machine data and operating logs in accordance with DIN 10510. So whenever you need to perform an analysis or diagnostic process, you have the reassurance of knowing that all the data is on hand. With CC you can select the specific operating log you need from the memory, automatically transfer operating logs to a local PC, archive operating logs on a local PC, and send data by e-mail.
CC comes with an update function which provides convenient access to software upgrades and updates.
