Food waste treatment system MEIKO BioMaster®

Servicing and technical data

ADVANTAGES

  • No open buckets or bins of food waste to move around

  • No unpleasant odours

  • No flies, vermin or mould spores

  • Compact, stand-alone appliance requiring little space

  • Fully integratable

  • Less collection by waste disposal firms

MODELS

for kitchen waste and leftovers

Whether you serve 100 or more than 10,000 covers per day – we have the right solution for your needs with the BioMaster® waste treatment system.

MEIKO BioMaster®4 PLUS

The BioMaster® 4 PLUS comes on the same chassis as the BioMaster®4 HIGHLINE: 150 mm ground clearance, can be plinth-mounted, easy to clean, standard-compliant water supply, attaches to tables and hygiene stations, yet this appliance is in a class of its own. The right machine for use in medium to large commercial kitchens. Kitchen waste and leftovers can be processed in just 50 seconds. From breakfast to dinner, norm-compliant processing is guaranteed. A symbiosis between power and design.

Measurements
Dimensions (W x Hmin x D)700 x 700 x 865 - 935 mm
Chassismade entirely of AISI 304 / V2A stainless steel - high-quality finishing
Chute volume40 l
Capacity≤ 1000 kg/h
Feed pump „BioPump®“1.1 kW, max. 80 l/min.
Macerator3 kW
Biomass outlet connectionPE d-63 screw fitting
Cold water connection¾'' male thread
Addition of process waterprogrammable, adjustable water flow
Electrical connectionCEE plug, 400 V, 50Hz, 4.5 kW, clockwise rotational field, 16 A (fuse) / Residual Current Protective Devices (RCD) - Type A with 30mA trip current
Protection class of the machineIP X5
Noise emission≤ 70 dB
Leergewicht185 kg
Additional equipmentunlocking key, three collection buckets, patented pre-mincing unit funnel top as splashguard
