Rack Conveyor Dishwasher KA SERIES

Service and technical data

industrial warewasher UPster K

BENEFITS

  • Ultimate wash performance with minimum space requirement
  • Hygienic glass display with touch function
  • Intuitive operating concept – optimum operator guidance
  • Auto timer for maximum profitability
  • Easy cleaning thanks to high floor clearance
  • Large passing height allows even the largest tableware to be cleaned

MODELS

A new generation of rack type dishwashing machines

The best quality clean in the smallest possible space. This is the quickest way to describe the UPster commercial dishwasher. A choice of lengths gives you exactly the dishwashing capacity you need. A new generation of rack type dishwashing machines.

KA 44

Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
KA 54

Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
KA 64

Depth795 mm
Height1,934 mm
Rack capacity (min.)355 racks/hr
Rack capacity (max.)355 racks/hr
KA 66

Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
KA 76

Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
KA 80

Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
KA 86

Depth795 mm
Height1,934 mm
Rack capacity (min.)355 racks/hr
Rack capacity (max.)355 racks/hr
KA 90

Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
KA 100

Depth795 mm
Height1,934 mm
Rack capacity (min.)355 racks/hr
Rack capacity (max.)355 racks/hr
KA 44

Double-wall insulation minimizes noise and heat loss while keeping the exterior of the equipment cool to the touch. Slotted, concave wash nozzles deliver superior cleaning for all your wares—from dishes, to pots and pans, cutlery and more. With water consumption of only 0.29 gallons (1.11 liters) per rack and a 20ʺ (508mm) tunnel height, the KA-44 delivers maximum washing performance in a minimal space.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse71.0 U.S.gals/hr / 268.8 l/hr
Total connected load20,1 kW
Machine length1104 mm
KA 54

Featuring a 3hp wash pump and a 20ʺ (508mm) clearance height inside the wash chamber, the KA-54 easily tackles up to 243 racks per hour. Its high-contrast, glass touch screen display is designed to keep operators fully informed at every stage of the washing process—simplified service diagnostics, error logging, troubleshooting and real-time performance updates are accessible with straightforward, one-touch operation.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse71.0 U.S.gals/hr / 268.8 l/hr
Total connected load20,1 kW
Machine length1358 mm
KA 64

The KA-64 is your solution for faster, cleaner results. Standard features like a built-in ‘smart’ booster heater with power rinse pump, a 20ʺ (508mm) tunnel height, and sealed, reversible hinged doors help this dish machine deliver superior performance without increasing its price. Best described as a workhorse, the KA-64 can easily tackle any job your kitchen can dish out.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)355 racks/hr
Rack capacity (max.)355 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse85.9 U.S.gals/hr / 325.5 l/hr
Total connected load39,5 kW
Machine length1612 mm
KA 66

Advanced technology and smart design make the KA-66 economical, reliable and easy to use. Its optional Waste Air Heat Recovery System (WAHRS) reclaims and reuses heat generated by the machine—reducing energy consumption and allowing hot-water sanitization from a cold water supply. Water usage remains low at 0.29 gallons (1.11 liters) per rack while maintaining a maximum capacity of 243 racks per hour.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse71.0 U.S.gals/hr / 268.8 l/hr
Total connected load20,1 kW
Machine length1663 mm
KA 76

The KA-76 is built to save water, energy and chemicals, to save you money. It’s the perfect replacement for your old, inefficient dish machine. It cleans up to 243 racks per hour while still maintaining low water and energy usage. The optional Waste Air Heat Recovery System (WAHRS) helps maintain optimal indoor air quality for staff in back-of-house areas.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse71.0 U.S.gals/hr / 268.8 l/hr
Total connected load20,1 kW
Machine length1917 mm
KA 80

Does your heavily-soiled ware need more time in the tunnel? Eggs, cheese and other clingy food scraps are no match for the KA-80. The unique wash arm spray pattern of its separate pre-wash tank efficiently rids your wares of stuck-on food—and that’s before the heated wash tank easily removes any remaining food particles. Add the optional blower-dryer module to reduce drying time and spotting on ware.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse71.0 U.S.gals/hr / 268.8 l/hr
Total connected load22,3 kW
Machine length2019 mm
KA 86

MEIKO’s KA-86 has the incredible ability to adapt to the processes you need. Dishes, glasses, trays, sheet pans and cutlery each have their own specific wash process requirements—this dishwasher can deliver on them all. Its low water consumption of 0.24 gallons (0.92 liters) per rack still provides a maximum capacity of 355 racks/hour. Three conveyor speeds efficiently handle varying levels of soiling, guaranteeing the clean you need.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)355 racks/hr
Rack capacity (max.)355 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse85.9 U.S.gals/hr / 325.5 l/hr
Total connected load39,5 kW
Machine length2171 mm
KA 90

Don’t wonder if your food wares have been properly cleaned: Be sure. Like all KA Series models, the advanced technology of the KA-90, combined with MEIKO’s warewashing processing conditions, is verified to inactivate coronavirus in ONE WASH CYCLE. Standard features such as double-wall insulation, a built-in booster heater, and a 20ʺ (508mm) tunnel height aid this dish machine in safely disinfecting heavily-soiled wares.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)243 racks/hr
Rack capacity (max.)243 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse71.0 U.S.gals/hr / 268.8 l/hr
Total connected load22,3 kW
Machine length2273 mm
KA 100

More mechanical action means better results—wares washed in the KA-100 are no match for its ultimate cleaning power. Absolute cleanliness and safety are balanced with water and energy conservation. The 36ʺ pre-wash tank and two heated wash tanks easily cleans up to 355 racks per hour, but its sustainable design is guaranteed to save you big on labor, water, energy and chemicals.

Measurements
Depth795 mm
Height1,934 mm
Rack capacity (min.)355 racks/hr
Rack capacity (max.)355 racks/hr
Rack dimension 500 x 500 mm mm
Passing height508 mm
Passing width510 mm
Final rinse85.9 U.S.gals/hr / 325.5 l/hr
Total connected load41,7 kW
Machine length2527 mm

RACKS

RACK FOR REUSABLE DISHWARE

This rack is a great way to assure hygiene safety in bowl cleaning. Accommodates up to six bowls as well as their lids.

PROTECTIVE COVER

Height: 1.6 m

TILTERS

We are able to equip glass racks with tilters on request. These help water to drain out of your glassware

ROLB 500

Platform trolley with drip tray and handle for pushing.

RACK STORAGE UNIT

To be installed under table, can be individually adjusted for different rack heights

NK BASE RACK WITH WHT INSERT

For 4 warmer trays, cutout on one side, stainless steel insert

NK BASE RACK WITH NKT INSERT

For 9 trays, cutout on one side, white insert, polyamide coated

VKV 50 TKT TRAY RACK

For GN trays with lateral opening and with stainless steel reinforced profiles

CUTLERY INSERT

With 7 compartments with VKV 50/1 universal finger rack

KV 34 X 15/1 CUTLERY BASKET

Made of perforated metal sheeting, with 8 compartments (340 x 150 mm)

CBS CUTLERY QUIVER

(Also suitable for rack size 400)

BKS CUTLERY BASKET

With 8 slots, 430 x 210 mm

BV 100 X 50/1

Rack with wheels, made from solid stainless steel, not suitable for inserting into 500 x 500 mm base racks, (interior dimensions 970 x 470 mm)

BV 131 X 70/1

Rack with wheels (1,310 x 700 mm), made from solid stainless steel

BV 131 X 69/1

Rack with wheels (1,310 x 690 mm), made from solid stainless steel

BV 60 X 50/1

Rack insert for baking trays, made from solid stainless steel (600 x 500 mm) 20–30 mm baking tray depth = 11

BV 60 X 50/2

Rack insert for baking trays, made from solid stainless steel (600 x 500 mm) 30–50 mm baking tray depth = 9 trays

BV 60 X 50/3

Rack insert for baking trays, made from solid stainless steel (600 x 500 mm) up to 70 mm baking tray depth = 6 trays

BV 60 X 39 RACK INSERT

(608 x 390 mm) made from solid stainless steel

BV 60 X 50/10 RACK

For 2/1 GN containers (max. 150 mm depth) made from stainless steel

UV 67 X 39 UNIVERSAL RACK INSERT

(670 x 390 mm) made from solid stainless steel

BV 57 X 56 RACK INSERT

(570 x 560 mm) solid stainless steel rack insert for 2–8 GN containers, 1/2–1/1 (max. 65, 100, 150 mm depth)

BV 85 X 70/1 RACK WITH WHEELS

(850 x 700 mm) made from solid stainless steel

BV 60 X 50/9 RACK

Use as tilter for transport containers (600 x 400 mm), made from stainless steel

BV 60 X 50/8 RACK

For 8 display trays/platters/trays (max. 650 x 530 mm, GN 2/1) made from stainless steel

TV 65 X 50/1 PLATE RACK

White, polyamide coated, 8 rows (650 x 500 mm, plate dia. up to 320 mm)

TV 50-22 RACK

Made from stainless steel for 8 display trays (600 x 400 mm)

VKV 60/G GLASS RACK

Rack size 600 x 400 mm, compartments for 15–40 glasses and for different heights of glass

VKV 60/T PLATE RACK

Base rack, 600 x 400 mm with stainless steel insert with or without wheels for large plates, white, polyamide coated, 8 rows, plates up to 320 mm in dia.

DRIP TRAY

For 400 x 400 mm racks

VKV 40/7 PLATE INSERT

For 10 plates designed to fit in VKV 40/4 base rack (rack size 400 x 400 mm)

GV 40/12 GLASS RACK

White, polyamide coated, with sloping base and 3 rows for glasses up to 121 mm in dia., rack height 150 mm, (rack size 400 x 400 mm)

GV 40/9 GLASS RACK

White, polyamide coated, with sloping base and 4 rows for glasses up to 96 mm in dia., rack height 150 mm, (rack size 400 x 400 mm)

GV 40/15 GLASS RACK

With 4 removable stacking rows, tilts glasses (rack size 400 x 400 mm)

VKV 40/4 BASE RACK

Close mesh, height 150 mm (rack size 400 x 400 mm)

UV 40/3 UNIVERSAL RACK

White, polyamide coated, for glasses, cups, saucers, plates up to 200 mm in dia. and cutlery (rack size 400 x 400 mm)

GV 40/10 UNIVERSAL RACK

White, polyamide coated, with tilted base for glasses up to 97 mm, cups, saucers, plates up to 200 mm in dia., rack height 220 mm (rack size 400 x 400 mm)

VKV 40/15 GLASS RACK

Wide mesh, rack height 260 mm with compartments for 16 glasses (rack size 400 x 400 mm)

VKV 40/14 GLASS RACK

Wide mesh, rack height 200 mm with compartments for 16 glasses (rack size 400 x 400 mm)

VKV 60/1 PLATE RACK

For 22 plates, or even 24 plates if flat. Offset rack design ensures plates up to approx. 28 cm in diameter do not touch each other. Flat (pizza) plates up to 32 cm in diameter.

VKV 60/2 SMALL PARTS RACK

Base rack for cutlery baskets, pots, bowls, kitchen utensils, cups (rack size 600 x 500 mm)

VKV 60/3 TRAY RACK

For 12 small trays or 10 GN trays (rack size 600 x 500 mm)

DRIP TRAY

For 500 x 500 mm racks

UV 50/5 TRAY RACK

White, polyamide coated, for 530 x 325 mm GN trays and large, flat plates (rack size 500 x 500 mm)

GV 50/17 UNIVERSAL RACK

White, polyamide coated, for glasses, cups, saucers, plates up to 200 mm in dia. and cutlery (rack size 500 x 500 mm)

GV 50/21 GLASS RACK

With 5 rows, glasses up to 90 mm in dia., rack height 220 mm (rack size 500 x 500 mm)

GV 50/23 GLASS RACK

With 5 rows, glasses up to 90 mm in dia., rack height 150 mm (rack size 500 x 500 mm)

GV 50/20 GLASS RACK

White, polyamide coated. With 4 rows, glasses up to 110 mm in dia., rack height 220 mm (rack size 500 x 500 mm)

GV 50/22 GLASS RACK

White, polyamide coated. With 4 rows, glasses up to 110 mm in dia., rack height 150 mm (rack size 500 x 500 mm)

VKV 50/G 711 GLASS RACK

For 49 glasses, max. glass dia.: 63 mm, max. glass height: 110 mm (rack size 500 x 500 mm)

VKV 50/G 611 GLASS RACK

For 36 glasses, max. glass dia.: 74 mm, max. glass height: 110 mm (rack size 500 x 500 mm)

VKV 50/G 521 GLASS RACK

For 25 glasses, max. glass dia.: 90 mm, max. glass height: 210 mm (rack size 500 x 500 mm)

VKV 50/G 516 GLASS RACK

For 25 glasses, max. glass dia.: 90 mm, max. glass height: 160 mm (rack size 500 x 500 mm)

VKV 50/G 416 GLASS RACK

For 16 glasses, max. glass dia.: 113 mm, max. glass height: 160 mm (rack size 500 x 500 mm)

NK 130 UNIVERSAL BASE RACK

Clearance height 130 mm, can also be used as a base rack for cutlery baskets (rack size 500 x 500 mm)

NK 110 UNIVERSAL BASE RACK

Clearance height 110 mm, can also be used as a base rack for cutlery baskets (rack size 500 x 500 mm)

GV 50/25 GLASS RACK

With 5 removable stacking rows, tilts glasses (rack size 500 x 500 mm)

P 15 PLATE RACK

For 15 large plates, suitable for plates with min. dia. 180 mm (rack size 500 x 500 mm)

NK BASE RACK WITH PTE INSERT

For 9 large plates, white insert, polyamide coated (rack size 500 x 500 mm)

TAV CUP RACK INSERT

White, polyamide coated, with sloping rows for VKV 50/2 small parts rack (rack size 500 x 500 mm)

VKV 50/2 BK SMALL PARTS RACK

(Close mesh) for small cutlery items (rack size 500 x 500 mm)

VKV 50/2 SMALL PARTS RACK

Can also be used as a base rack for BKO cutlery basket (rack size 500 x 500 mm)

UV 46 X 46/1 COVER SCREEN

White, polyamide coated, prevents lightweight items from lifting out of VKV 50/2 or VKV 50/2 BK small parts rack (rack size 500 x 500 mm)

VKV 50/1 PLATE RACK

For plates, dishes, cups and saucers (rack size 500 x 500 mm)

BOTTLE RACK

Bottle rack with adapter for rinsing bottles, carafes, jugs. (Rack size: 500 x 500 mm). Max. bottle height (depending on the outer diameter of the bottle neck) 230–245 mm in the case of the M-iClean UM and 355–370 mm when using the M-iClean UM+
